İşlemci |
High‐performance TI DaVinci DSP |
Sensör |
1/2.5" 5MP progressive scan CMOS |
Shuttle zamanı |
1/5s to 1/50,000s |
Lens Mount |
C/CS Mount |
Auto Iris |
DC drive |
Day&Night |
IR cut filter with auto switch |
VideoSıkıştırma |
H.264/MJPEG |
H.264 coding standard |
H.264 Baseline/MainProfile/HighProfile |
Ses Sıkıştırma |
G.711a/G.711u/RAW_PCM |
Ses Bit Rate |
G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps) |
Max Görüntü Boyutu |
2592(H)×1920(V) |
Akış |
Çift‐akış |
Ana Akış |
50Hz:10fps (2592 × 1920), 60Hz:10fps (2592 × 1920), |
|
20fps (2048 × 1536), 20fps (2048 × 1536), |
Frame Rate |
25fps (1920 × 1080); 30fps (1920 × 1080); |
Alt‐akış |
50Hz: 25fps(640 × 480); 60Hz: 30fps (640 × 480); |
Hafıza Kartı |
SD/SDHC (Max 32GB) |
|
Motion detection, tampering alarm, network |
Alarm Tetikleme |
disconnect, storage exception |
Protokoller |
IPv4/IPv6、RTSP/RTP/RTCP、TCP/UDP、HTTP、DHCP, DNS、FTP、DDNS、PPPoE、SMTP、Onvif |
Onvif |
V2.4 Version |
Ses In |
1‐kanal 3.5mm Ses arayüz MIC IN/Line IN |
Ses Out |
1‐kanal 3.5mm Ses arayüz (line level,600Ω) |
RS485 |
Evet (half duplex) |
Alarm |
1 In/1 Out |
Video Out |
1Vp‐p Composite Output(75Ω/BNC) |
Network |
1 RJ45 10M/100M adaptive Ethernet port |
Reset |
Reset düğmesi ( basın ve 3 sn basılı tutun) |
Çalışma Koşulları |
‐40℃ ~ 60℃, 95%ve altı nemlilik |
Güç İhtiyacı |
DC12V±10%,PoE (802.3af) |
Güç Tüketimi |
2.5W |
Boyutlar(mm) |
150.2×77.7×55.8 |
Ağırlık(kg) |
0.51 |
